Chapter 2: Fast, Asynchronous SRAM
The SRAM array forms either a single 256Kx32 SRAM memory or two independent
256Kx16 arrays. Both SRAM devices share common write-enable (WE#), output-enable
(OE#), and address (A[17:0]) signals. However, each device has a separate chip select
enable (CE#) control and individual byte-enable controls to select the high or low byte in
the 16-bit data word, UB and LB, respectively.
The 256Kx32 configuration is ideally suited to hold MicroBlaze instructions. However, it
alternately provides high-density data storage for a variety of applications, such as digital
signal processing (DSP), large data FIFOs, and graphics buffers.
Address Bus Connections
Both 256Kx16 SRAMs share 18-bit address control lines, as shown in Table 2-1 . These
address signals also connect to the A1 Expansion Connector (see “Expansion Connectors,”
page 47 ).
Table 2-1:
External SRAM Address Bus Connections to Spartan-3 FPGA
12
Address Bit
A17
A16
A15
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A0
FPGA Pin
L3
K5
K3
J3
J4
H4
H3
G5
E4
E3
F4
F3
G4
L4
M3
M4
N3
L5
www.xilinx.com
A1 Expansion Connector Pin
35
33
34
31
32
29
30
27
28
25
26
23
24
14
12
10
8
6
Spartan-3 FPGA Starter Kit Board User Guide
UG130 (v1.2) June 20, 2008
